產品名稱：GWDL-TY高溫陶瓷纖維異形件

型號：GWDL-TY高溫陶瓷纖維異形件

規格：GWDL-TY高溫陶瓷纖維異形件

備注：GWDL-TY高溫陶瓷纖維異形件

該產品系采用多晶氧化鋁纖維為主要原料，復配填料和粘合劑等，以吸-壓結合的方式成型。根據用戶要求的形狀、尺寸和容重進行生產?？蓾M足最高1800℃，長期1750℃的使用要求，已在多座窯爐上替代進口產品使用，節能效果良好，降低了使用成本。

The products are fabricated by suck-press combined method using polycrystalline alumina fiber as main starting materials, adding packing materials and binders. Special shaped products with different volume weights and specifications can be produced in accordance with design drawing of user.The products can long term serve at 1 750 ℃ and at 1 800 ℃ of the maximum, and have been used in many kilns to substitute imported products, saving energy and cutting cost.

產品性能

Product specification

型號參數		GWDL-TY-1000	GWDL-TY-1260	GWDL-TY-1420	GWDL-TY-1500	GWDL-TY-1600	GWDL-TY-1700	GWDL-TY-1800	GWDL-TY-1850
最高使用溫度，℃ Max. service temperature		1000	1260	1420	1500	1600	1700	1800	1850
長期使用溫度（爐溫），℃ Long-term service temperature(furnace temperature)℃		950	1200	1350	1450	1550	1650	1750	1800
制品容重，kg.cm-3 Volume weight		300-600	300-600	400-700	400-700	400-700	400-700	450-700	500-700
導熱系數w·(m·K)-1,1200℃ Thermal conductivity		0.14	0.145	0.155	0.15	0.155	0.16	0.17	0.2
加熱線收縮率，% Linear shrinkage on heating	1000	≤1	/	/	/	/	/	/	/
	1200	/	≤0.5	≤0.2	/	/	/	/	/
	1400	/	/	≤1	≤0.2	/	/	/	/
	1500	/	/	/	≤1	≤0.2	/	/	/
	1600	/	/	/	/	≤2	≤0.3	/	/
	1700	/	/	/	/	/	≤2	≤0.6	≤0.8
	1800	/	/	/	/	/	/	≤2	≤0.5

應用　Application

高溫電爐爐襯、儀器設備加熱裝置的隔熱及電絕緣材料；隧道窯、輥道窯的窯襯材料。

Used as thermal and electric insulating materials for high temperature electric furnace and heating units of equipment, and lining materials for tunnel kiln and roller kiln

產品規格，mm

Product specification

根據用戶需要定做

in accordance with design drawing of user

注：產品的技術數據是由所采用的測試標準得的平均值，會在一定的范圍內波動，該數據不代表產品的質量保證數據。
